Product Overview

The build up of grain dust can pose the very real and immediate threat of a combustible dust explosion inside your food and grain manufacturing or storage facilities. To prevent such a catastrophe from happening, you need Ruwac’s FRV Series portable explosion-proof vacuums. Manufactured under strict quality control here in the United States, our certified explosion-proof vacuums are intrinsically safe with all parts fully grounded, static dissipating, and guaranteed to be spark-free by impact.

  • OSHA compliant
  • Certified explosion proof vacuums ETL certified to UL standards for combustible dust collection Class I, Group D and Class II, Group F & G
  • Under 8 cubic feet certified for indoor use
  • Continuous duty rated and completely serviceable nationwide
  • Compression cast composite housing will not dent, break or rust — Backed by Ruwac’s lifetime guarantee!
  • Carbon impregnated housing is chemically neutral and static dissipating (<10-6 Ohms) to eliminate static discharge
  • Modular housing for easy filter upgrades such as HEPA
  • Industry-leading MicroClean filter is 99.9% efficient at 0.5 microns, preventing filter clogs and cutting down on costly filter replacements
  • Foot-actuated 9 gallon dustpan allows for easy, dust-free emptying

Electric Explosion Proof Food & Grain Vacuums

Product CFM Pressure (Hg”) Motor Phase Volts Horsepower Amps Filter Size (sq. ft.)
FRV1400 Explosion Proof Vacuum
FRV1400
300 CFM 6.2 Hg” Three
208, 230 / 460 Volts
5 Hp 17, 7 Amps 28 sq. ft.
FRV Series Explosion Proof Vacuum
FRV110
150 CFM 5.5 Hg” Single 110 Volts 1.5 Hp 16 Amps 13 sq. ft.

Air Powered Explosion Proof Food & Grain Vacuums

Product CFM Pressure (Hg”) Motor Phase Volts Horsepower Amps Filter Size (sq. ft.)
FRV100 Air-Powered Explosion Proof Vacuum
FRV100
150 CFM 13 Hg”

Single Stainless Steel Venturi

(requires 71 PSI)

n/a
n/a n/a 13 sq. ft.
FRV100 Air-Powered Explosion Proof Vacuum
FRV200
275 CFM 16 Hg”

Dual Stainless Steel Venturi

(requires 100 PSI)

n/a n/a n/a 28 sq. ft.
